DC9-24V Car Offroad 4x4 LED Work Light Bar Wireless Flash Remote Control Switch Kit Spotlight Wiring Set

SKU: #7127
Old price: 12.23 (GBP)
5.86 (GBP)
PRICE BREAKS - The more you buy, the more you save
Quantity1+7+13+19+27+
Price5.86 (GBP)5.57 (GBP)5.40 (GBP)5.28 (GBP)4.20 (GBP)
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Specifications:
Controller Material: Tinned Wird, PVC
Current:40A Power Relay
Load capacity: Max.180W/300W for your choice
Inline Blade 30A Fuse
With a switch control, and support to work with remote switch
Hook with 1 Light with 180W/300W

Fitment:
Details Makes Perfect:adopt flexible strand copper wire,up to 180 watt load capacity.
It is universal fit for any 7" 10" 12" 20" 30" 40" 50 "  52 "  light bars that is within 180w or 300w .
Great Construction:40A Power Relay and Inline Blade Fuse for multiple safety protection.
With 1 or 2 lights output connections,it can hook with 1 or 2 led work light or 1 or 2 small watt led light bar and any else off road LEDs.

Wireless remote control working mode:
1. Indicator light: When the ON key, OFF key, single flash key or double flash key is arbitrarily pressed, the indicator light will be ON
2.0FF key: When this key is pressed, the lights turn off
3.0N key: When pressed this key, the car lights long light
4. Double flash key:
(1) Blink every 0.1 seconds (blink means that the time on and off is the same) for 5 times and then turn off 0.5 seconds. One beat cycle is 1 second
(2)2 the first 0.25 seconds half light, then 0.25 seconds full light, after 0.5 seconds off a beat cycle is 1 second (this function is changed to :0.1 seconds under 1 frequency is always in sequence, no interval)
(3) Blink twice slowly for the first 0.4 seconds and blink three times quickly for the second 0.6 seconds before closing one beat. The cycle is 1 second
(4) Blink twice slowly for the first 0.8 seconds and then blink three times fast for the second 0.8 seconds and then turn off one beat. The cycle is 1.5 seconds
(5) Blink 3 times slowly for the first 1.5 seconds, and blink 12 times quickly for the second 2.5 seconds. The next beat period is 4 seconds
(6) Blink continuously every second (blink means the time on and off is equal)4 times and then close 0.2 seconds. One beat cycle is 1 second
5. Single flash button:
(1) Continuously blink every second (blink means that the time on and off is equal)4 times and then close 0.2 seconds. One beat cycle is 1 second
(2) Blink three times at a slow rate of 1.5 seconds and then blink 12 at a quick rate of 2.5 seconds. The next beat period is 4 seconds
(3) Blink twice slowly for the first 0.8 seconds and blink three times quickly for the second 0.8 seconds and then turn off one beat for 1.5 seconds
(4) Blink twice slowly for the first 0.4 seconds, blink three times quickly for the second 0.6 seconds, and then turn off one beat. The cycle is 1 second
(5) The first 0.25 seconds half light, then 0.25 seconds full light, after 0.5 seconds off a beat cycle is 1 second (this function is changed to :0.1 seconds under 1 frequency has been in sequence, no interval)
(6) Flash every 0.1 seconds (flash means the time on and off is the same)5 times and then off for 05 seconds. One beat cycle is 1 second
